· Dust removal: water washing, filtration, etc.
· Acid removal / alkali: neutralization absorption
· Dehumidification: heating, condensation-heating
· Cooling: heat exchanger
Waste Gas Treatment
Waste Gas Treatment
1. (VOCs)
volatile organic compound
administer
Step2 the main processing process
· Zeolite molecular sieve adsorption
· Activated carbon adsorption
· RTO / RCO / CO / TO
· Condensation method
· Biological method
· Process combination
Step3 the post-processing process
· Acid removal: neutralization absorption
· NOx: catalytic reduction
· Erga ying: adsorption method
2. VOCs recovery and emission reduction technology based on special material adsorption
Special adsorption material is high molecular polymer
|
adsorbent |
Activated carbon fiber |
acticarbon |
Special adsorption materials |
|
adsorbed object |
Not suitable for ketones, esters, halogenated hydrocarbons, etc |
Not suitable for ketones, esters, halogenated hydrocarbons, etc |
No restrictions |
|
Removal efficiency |
Gradually attenuation |
Gradually attenuation |
High,stable |
|
Replacement cycle |
2~3 Years |
6 months to1year |
non-renewal |
|
Steam dosage (per ton of solvent) |
7~10t |
7~10t |
2~3t |
This technology has high mechanical strength and stable adsorption performance, so it is successfully applied to the treatment of dichloromethane, dichloroethane, chloroform, toluene, ethyl ethyl methyl isobutylmethyl one, n-hexane and 120 # solvent oil, which is especially suitable for the recycling of chlorine-containing organic matter.
